Z0603C Series

Manufacturer: KEMET

Catalog

FERRITE BEAD 150 OHM 0603 1LN

Part	Number of Lines	DC Resistance (DCR) (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [z]	Height (Max) [z]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Current Rating (Max) [Max]	Filter Type	Mounting Type	Impedance @ Frequency	Size / Dimension [y]	DC Resistance (DCR) (Max)
KEMET Z0603C151BPWZT	1	50 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	2 A	Power Line	Surface Mount	150 Ohms
KEMET Z0603C102BSMST	1	700 mOhm	0.031 in 0.032 in	1.6 mm	0.8 mm	0.063 "	0.95 mm	0.037 in	125 °C	-55 C	1608 Metric	0603	200 mA	Signal Line	Surface Mount	1 kOhms	0.8 mm
KEMET Z0603C101BPWZT	1	35 mOhm	0.031 in 0.032 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	2 A	Power Line	Surface Mount	100 Ohms	0.8 mm
KEMET Z0603C601GPWZT	1	450 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	400 mA	Power Line	Surface Mount	600 Ohms
KEMET Z0603C152DSMST	1	750 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.95 mm	0.037 in	125 °C	-55 C	1608 Metric	0603	250 mA	Signal Line	Surface Mount	1.5 kOhms
KEMET Z0603C102ASMST	1		0.031 in 0.032 in	1.6 mm	0.8 mm	0.063 "	0.95 mm	0.037 in	125 °C	-55 C	1608 Metric	0603	300 mA	Signal Line	Surface Mount	1 kOhms	0.8 mm	600 mOhm
KEMET Z0603C331BPWZT	1	130 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	900 mA	Power Line	Surface Mount	330 Ohms
KEMET Z0603C471BPWZT	1	150 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	700 mA	Power Line	Surface Mount	470 Ohms
KEMET Z0603C331GPWZT	1	210 mOhm	0.031 in	1.6 mm	0.8 mm	0.063 "	0.9 mm	0.035 in	125 °C	-40 C	1608 Metric	0603	600 mA	Power Line	Surface Mount	330 Ohms
KEMET Z0603C101APMST	1	50 mOhm	0.031 in 0.032 in	1.6 mm	0.8 mm	0.063 "	0.95 mm	0.037 in	85 °C	-55 C	1608 Metric	0603		Power Line	Surface Mount	100 Ohms	0.8 mm
