CP3500 Series
Manufacturer: OmniOn Power™
Beta
⌘K
AC/DC CONVERTER 54V 3500W
| Part | Applications | Mounting Type | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output 1 | Voltage - Output 1 | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Features | Voltage - Isolation | Type | Voltage - Input [Min] | Voltage - Input [Max] | Number of Outputs | Power (Watts) | Minimum Load Required | Standard Number | Voltage - Output 1 [custom] | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OmniOn Power™ | ITE (Commercial) | Rack Mount | 91 % | 75 ░C | -10 °C | 64.8 A | 54 V | 1.63 in | 13.85 in | 4 " | 351.2 mm | 101.6 mm | 41.4 mm | 80 Plus® Gold Adjustable Output Hot Swappable I2C Interface Load Sharing PMBus™ PFC Remote On/Off Remote Sense Standby | 3000 V | Front End | 90 VAC 185 VAC | 140 VAC 300 VAC | 1 | 3.5 kW | ||||
 OmniOn Power™ | ITE (Commercial) | Rack Mount | 96 % | 55 °C | -40 C | 57.4 A | 1.63 in | 13.85 in | 4 " | 351.8 mm | 101.6 mm | 41.4 mm | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Remote Sense Standby Output | 3000 V | Front End | 90 VAC 185 VAC | 140 VAC 265 VAC | 1 | 3731 W | 60950-1 | 65 V | CE | ||
 OmniOn Power™ | ITE (Commercial) | Rack Mount | 96 % | 75 °C | -10 °C | 67.3 A | 52 V | 1.63 in | 13.85 in | 4 " | 351.8 mm | 101.6 mm | 41.4 mm | Adjustable Output I2C Interface Load Sharing PMBus™ Remote On/Off Standby Output | 3000 V | Enclosed | 90 VAC | 265 VAC | 1 | 3.5 kW | 60950-1 | CE | ||
OmniOn Power™ | ITE (Commercial) | Rack Mount | 91 % | 75 ░C | -10 °C | 64.8 A | 54 V | 1.63 in | 13.85 in | 4 " | 351.2 mm | 101.6 mm | 41.4 mm | 80 Plus® Gold Adjustable Output Hot Swappable I2C Interface Load Sharing PMBus™ PFC Remote On/Off Remote Sense Standby | 3000 V | Front End | 90 VAC 185 VAC | 140 VAC 300 VAC | 1 | 3.5 kW | ||||
OmniOn Power™ | ITE (Commercial) | Rack Mount | 96 % | 75 ░C | -10 °C | 64.8 A | 54 V | 1.63 in | 13.85 in | 4 " | 351.2 mm | 101.6 mm | 41.4 mm | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Remote Sense Standby Output | 3000 V | Front End | 90 VAC 185 VAC | 140 VAC 300 VAC | 1 | 3.5 kW | CE | |||
OmniOn Power™ | ITE (Commercial) | Rack Mount | 96 % | 75 ░C | -10 °C | 64.8 A | 54 V | 1.63 in | 13.85 in | 4 " | 351.2 mm | 101.6 mm | 41.4 mm | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Remote Sense Standby Output | 3000 V | Front End | 90 VAC 185 VAC | 140 VAC 300 VAC | 1 | 3.5 kW | CE |
