G Series
Manufacturer: CW Industries
Beta
⌘K
SLIDE SWITCHES MINI SLIDE SWITCH
| Part | Mechanical Life | Actuator Material | Electrical Life | Switch Travel | Voltage Rating - DC | Actuator Length [x] | Actuator Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Contact Finish | Contact Timing | Switch Function | Circuit | Voltage Rating - AC | Current Rating (Amps) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | ||||||||||||||||||
CW Industries | 10000 Steps | Nylon 6/6 Polyamide (PA66) | 6000 Cycles | 6.25 mm | 125 VDC | 8.74 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-Mom | DP3T | 125 V | 3 A 500 mA | PC Pin |
CW Industries | ||||||||||||||||||
CW Industries | 125 VDC | 5.08 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-On | SP3T | 125 V | 500 mA | PC Pin | ||||
CW Industries | 125 VDC | 8.74 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-On | DP3T | 125 V | 6 A 500 mA | Wire Wrap | ||||
CW Industries | 10000 Steps | Nylon 6/6 Polyamide (PA66) | 6000 Cycles | 6.25 mm | 125 VDC | 8.74 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-On | DP3T | 125 V | 6 A 500 mA | PC Pin |
CW Industries | ||||||||||||||||||
CW Industries | 10000 Steps | Nylon 6/6 Polyamide (PA66) | 6000 Cycles | 6.25 mm | 125 VDC | 8.74 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-On | SP3T | 125 V | 3 A 500 mA | Wire Wrap |
 CW Industries | 10000 Steps | Nylon 6/6 Polyamide (PA66) | 6000 Cycles | 6.76 mm | 125 VDC | 8.74 mm | Standard | Panel Mount | -10 °C | 104 °C | Copper | Silver | Not Specified | On-On-On-On | DP4T | 125 V | 11 A 500 mA | PC Pin |
CW Industries | Not Specified | On-Off | SPST |
