RB751S40T Series

30 mA, 30 V, Schottky Barrier Diode

Catalog

30 mA, 30 V, Schottky Barrier Diode

Part	Operating Temperature - Junction [Min]	Operating Temperature - Junction [Max]	Supplier Device Package	Technology	Current - Average Rectified (Io)	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Voltage - Forward (Vf) (Max) @ If	Mounting Type	Speed	Speed	Package / Case	Grade	Qualification	Capacitance @ Vr, F	Reverse Recovery Time (trr)
ON Semiconductor RB751S40	-55 °C	125 °C	SOD-523F	Schottky	30 mA	500 nA	30 V	370 mV	Surface Mount	Any Speed	200 mA	SC-79 SOD-523F
ON Semiconductor NSVRB751S40T5G	-55 °C	125 °C	SOD-523	Schottky	30 mA	500 nA	30 V	370 mV	Surface Mount	Any Speed	200 mA	SC-79 SOD-523	Automotive	AEC-Q101
ON Semiconductor RB751S40P2T5G	-55 °C	150 °C	SOD-923	Schottky	30 mA	500 nA	30 V	370 mV	Surface Mount	Any Speed	200 mA	SOD-923			2 pF	8 ns
ON Semiconductor RB751S40T1	-55 °C	150 °C	SOD-523	Schottky	30 mA	500 nA	30 V	370 mV	Surface Mount	Any Speed	200 mA	SC-79 SOD-523
ON Semiconductor RB751S40-ON
ON Semiconductor NSVRB751S40T1G	-55 °C	150 °C	SOD-523	Schottky	30 mA	500 nA	30 V	370 mV	Surface Mount	Any Speed	200 mA	SC-79 SOD-523	Automotive	AEC-Q101

Catalog

30 mA, 30 V, Schottky Barrier Diode

Key Features

• Extremely Fast Switching Speed

• Extremely Low Forward Voltage: 0.28 V (Typ) @ IF= 1.0 mAdc

• Low Reverse Current

• Lead−Free Plating

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHSCompliant

Description

The Schottky diode is designed for high speed switching applications, circuit protection and voltage clamping. Extremely low forward voltage reduces conduction loss. The miniature surface mount package is excellent for hand held and portable applications where space is limited.
