747321 Series

Catalog

CONN D-SUB PLUG 25POS IDC

Part	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Color	Dielectric Material	Termination	Shell Material, Finish	Contact Finish	Number of Rows [custom]	Features	Material Flammability Rating	Contact Type	Mounting Type	Current Rating (Amps)	Connector Type	Number of Positions	Shell Size, Connector Layout	Shell Size, Connector Layout [x]	Connector Style	Flange Feature	Contact Finish Thickness	Contact Finish Thickness	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout
TE Connectivity AMP Connectors 747321-2	Phosphor Bronze	-55 C	105 ░C	Black	Thermoplastic	IDC Ribbon Cable	Steel	Gold	2	Feed Through	UL94 V-0	Signal	Free Hanging (In-Line)	1.25 A	Plug Male Pins	25	B DB	3	D-Sub	Housing/Shell (Unthreaded)	30 Áin	0.76 Ám
TE Connectivity AMP Connectors 747321-4	Phosphor Bronze	-55 C	105 ░C	Black	Thermoplastic	IDC Ribbon Cable	Steel	Gold	2	Feed Through	UL94 V-0	Signal	Free Hanging (In-Line)	1.25 A	Plug Male Pins	9			D-Sub	Housing/Shell (Unthreaded)	30 Áin	0.76 Ám	1	DE E
TE Connectivity AMP Connectors 747321-3	Phosphor Bronze	-55 C	105 ░C	Black	Thermoplastic	IDC Ribbon Cable	Steel	Gold	2	Feed Through	UL94 V-0	Signal	Free Hanging (In-Line)	1.25 A	Plug Male Pins	15			D-Sub	Housing/Shell (Unthreaded)	30 Áin	0.76 Ám			2
