EVU-F3 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

POT 10K OHM 1/20W LINEAR

Part	Mounting Type	Number of Gangs	Resistance (Ohms)	Adjustment Type	Termination Style	Number of Turns	Size - Body	Size - Body	Size - Body	Size - Body	Built in Switch	Actuator Length [z]	Actuator Length [z]	Taper	Power (Watts)	Power (Watts)	Tolerance	Actuator Diameter [diameter]	Actuator Diameter [diameter]	Actuator Type	Rotation	Resistance (Ohms)	Bushing Thread	Size - Body [x]	Size - Body [x]	Size - Body [y]	Size - Body [y]	Size - Body [z]	Size - Body [z]	Actuator Length [x]	Actuator Length
Panasonic Industrial Automation Sales EVU-F3LFL3B14	Snap In Through Hole	1	10k	Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░
Panasonic Industrial Automation Sales EVU-F3MFL3B54		1		Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	50 kOhms	M9 x 0.75
Panasonic Industrial Automation Sales EVU-F3LFL3D54	Snap In Through Hole	1		Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Logarithmic	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	50 kOhms
Panasonic Industrial Automation Sales EVU-F3MFL3B53		1		Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	5 kOhms	M9 x 0.75
Panasonic Industrial Automation Sales EVU-F3LFL3B24	Snap In Through Hole	1		Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	20 kOhms
Panasonic Industrial Automation Sales EVU-F3MFL3D14		1	10k	Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Logarithmic	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░		M9 x 0.75
Panasonic Industrial Automation Sales EVU-F3AF30B14	Snap In Through Hole	1	10k	Top Adjustment	Board Locks PC Pins	1					Detent	23.1 mm	0.909 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░			0.453 in	11.5 mm	0.374 in	9.5 mm	6.9 mm	0.272 in
Panasonic Industrial Automation Sales EVU-F3AF30D24	Snap In Through Hole	1		Top Adjustment	Board Locks PC Pins	1					Detent	23.1 mm	0.909 in	Logarithmic	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	20 kOhms		0.453 in	11.5 mm	0.374 in	9.5 mm	6.9 mm	0.272 in
Panasonic Industrial Automation Sales EVU-F3MFL3B24		1		Top Adjustment	Board Locks PC Pins	1	0.335 " 0.382 " 0.492 "	12.5 mm	8.5 mm	9.7 mm	Detent	21.5 mm	0.846 in	Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	20 kOhms	M9 x 0.75
Panasonic Industrial Automation Sales EVU-F3KFK6B53	Snap In Through Hole	1		Top Adjustment	Board Locks PC Pins	1					Detent			Linear	0.05 W	50 mW	20 %	0.236 in	6 mm	Flatted	300 ░	5 kOhms								0.886 in	22.5 mm
