Spot-On Wire-to-Board Header with Nail, 2.00mm Pitch, Dual Row, Vertical, 22 Circuits, with Potting Capability, Matte Tin (Sn) Plating, Natural
Spot-On Wire-to-Board Header with Nail, 2.00mm Pitch, Dual Row, Vertical, 22 Circuits, with Potting Capability, Matte Tin (Sn) Plating, Natural
Spot-On Wire-to-Board Header with Nail, 2.00mm Pitch, Dual Row, Vertical, 22 Circuits, with Potting Capability, Matte Tin (Sn) Plating, Natural
| Part | Applications | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Height | Insulation Height | Number of Positions Loaded | Mounting Type | Features | Row Spacing - Mating | Row Spacing - Mating | Fastening Type | Style | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Voltage Rating | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Contact Finish - Post | Insulation Color | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Connector Type | Material Flammability Rating | Contact Material | Shrouding | Number of Rows [custom] | Termination | Contact Shape | Number of Positions | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Black | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 12 | Male Pin |
 Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Red | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 14 | Male Pin |
Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Black | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 24 | Male Pin |
 Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Yellow | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 22 | Male Pin |
 Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Blue | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 20 | Male Pin |
Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Red | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 28 | Male Pin |
Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Yellow | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 26 | Male Pin |
Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Yellow | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 18 | Male Pin |
 Molex | General Purpose | 39.4 çin | 1 çm | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Natural | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 30 | Male Pin |
 Molex | 0.354 in | 9 mm | All | Surface Mount | Solder Retention | 0.165 in | 4.2 mm | Latch Holder | Board to Cable/Wire | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 250 V | Varies by Wire Gauge | 0.079 " | 2 mm | Tin | Black | 39.4 µin | 1 µm | Header | UL94 V-0 | Brass | Shrouded - 4 Wall | 2 | Solder | Square | 16 | Male Pin |
