333-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Contact Finish | Number of Positions | Gender | Contact Material | Termination | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Rows [custom] | Read Out | Features | Pitch | Pitch | Flange Feature | Contact Type | Color | Card Thickness [Max] | Card Thickness [Min] | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 2 | Dual | Card Extender | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Through Hole | 2 | Dual | 3.96 mm | 0.156 in | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Right Angle Through Hole | 2 | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | 2 | Dual | 3.96 mm | 0.156 in | Flush Mount M3 Threaded Insert Top Opening | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Through Hole | 2 | Dual | 3.96 mm | 0.156 in | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | ||||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 28 | Gold | 28 | Female | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Right Angle Through Hole | Single | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Through Hole | 2 | Dual | 3.96 mm | 0.156 in | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 28 | Gold | 28 | Female | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Single | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | -40 C | 105 ░C | 14 | Gold | 28 | Female | Copper Alloy | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Through Hole | 2 | Dual | 3.96 mm | 0.156 in | 4-40 Threaded Insert Top Mount Opening | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 28 | Gold | 28 | Female | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Through Hole | Single | 3.96 mm | 0.156 in | Floating Bobbin Top Mount Opening | Cantilever | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 0.116 " | 2.95 mm | 1 | 1 |
