2.54mm Pitch SL Header, Single Row, Vertical, LCP, Shrouded, Through Hole, with Pegs, Matte Tin (Sn) Plating, 5 Circuits
2.54mm Pitch SL Header, Single Row, Vertical, LCP, Shrouded, Through Hole, with Pegs, Matte Tin (Sn) Plating, 5 Circuits
2.54mm Pitch SL Header, Single Row, Vertical, LCP, Shrouded, Through Hole, with Pegs, Matte Tin (Sn) Plating, 5 Circuits
| Part | Pitch - Mating | Pitch - Mating | Contact Length - Mating | Contact Length - Mating [x] | Connector Type | Contact Shape | Number of Positions | Contact Finish - Post | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Contact Material | Insulation Color | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Termination | Voltage Rating | Shrouding | Number of Positions Loaded | Style | Insulation Height | Insulation Height | Material Flammability Rating | Fastening Type | Contact Length - Post | Contact Length - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Mounting Type | Applications | Insulation Material | Contact Type | Features | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 0.1 in | 2.54 mm | 6.1 mm | 0.24 in | Header | Circular | 2 | Tin | -40 °C | 105 ░C | 3 A | Brass | Black | 2.54 µm | 100 µin | Solder | 250 VDC | Shrouded - 4 Wall | All | Board to Cable/Wire | 0.465 in | 11.8 mm | UL94 V-0 | Latch Holder | 0.13 in | 3.3 mm | 2.54 çm | 100 çin | Through Hole | General Purpose | Liquid Crystal Polymer (LCP) | Male Pin | Board Guide Polarizing Key | 1 |
 Molex | 0.1 in | 2.54 mm | 6.1 mm | 0.24 in | Header | Circular | Tin | -40 °C | 105 ░C | 3 A | Brass | Black | 2.54 µm | 100 µin | Solder | 250 VDC | Shrouded - 4 Wall | All | Board to Cable/Wire | 0.465 in | 11.8 mm | UL94 V-0 | Latch Holder | 0.13 in | 3.3 mm | 2.54 çm | 100 çin | Through Hole | General Purpose | Liquid Crystal Polymer (LCP) | Male Pin | Board Guide Polarizing Key | 1 | |
 Molex | 0.1 in | 2.54 mm | 6.1 mm | 0.24 in | Header | Circular | 4 | Tin | -40 °C | 105 ░C | 3 A | Brass | Black | 2.54 µm | 100 µin | Solder | 250 VDC | Shrouded - 4 Wall | All | Board to Cable/Wire | 0.465 in | 11.8 mm | UL94 V-0 | Latch Holder | 0.13 in | 3.3 mm | 2.54 çm | 100 çin | Through Hole | General Purpose | Liquid Crystal Polymer (LCP) | Male Pin | Board Guide Polarizing Key | 1 |
 Molex | 0.1 in | 2.54 mm | 6.1 mm | 0.24 in | Header | Circular | Tin | -40 °C | 105 ░C | 3 A | Brass | Black | 2.54 µm | 100 µin | Solder | 250 VDC | Shrouded - 4 Wall | All | Board to Cable/Wire | 0.465 in | 11.8 mm | UL94 V-0 | Latch Holder | 0.13 in | 3.3 mm | 2.54 çm | 100 çin | Through Hole | General Purpose | Liquid Crystal Polymer (LCP) | Male Pin | Board Guide Polarizing Key | 1 |
