SGT865 Series
Manufacturer: Celduc Inc.
Beta
⌘K
SSR RELAY SPST-NO 50A 24-520V
| Part | On-State Resistance (Max) [Max] | Mounting Type | Approval Agency | Package / Case | Voltage - Input [Max] | Voltage - Input [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Load Current | Voltage - Load [Max] | Voltage - Load [Min] | Output Type | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Celduc Inc. | 7.5 mOhms | Chassis Mount | CE | Module | 32 VDC | 4 V | -40 C | 100 °C | 50 A | 520 V | 24 V | AC Zero Cross | |
 Celduc Inc. | 7.5 mOhms | Chassis Mount | CE cURus EAC UKCA | Module | 255 VAC | 24 VAC | -40 C | 100 °C | 50 A | 520 V | 24 V | AC Zero Cross | 3PST-NO (3 Form A) |
