861400081 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN HEADER R/A 8POS 2.54MM
| Part | Termination | Fastening Type | Voltage Rating | Number of Rows | Material Flammability Rating | Contact Shape | Mounting Type | Contact Material | Connector Type | Number of Positions | Pitch - Mating | Pitch - Mating | Contact Type | Shrouding | Number of Positions Loaded | Insulation Height | Insulation Height | Insulation Material | Contact Length - Mating | Contact Length - Mating | Contact Length - Post | Contact Length - Post | Current Rating (Amps) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating | Insulation Height [z] | Insulation Height [z] | Overall Contact Length | Overall Contact Length | Operating Temperature [Min] | Operating Temperature [Max] | Contact Length - Mating [x] | Contact Length - Mating [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole Right Angle | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | 0.1 in | 2.54 mm | Thermoplastic | 0.197 in | 5 mm | 4.7 mm | 0.185 in | 3 A | |||||||||||
 Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole Right Angle | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | 0.1 in | 2.54 mm | Thermoplastic | 0.118 in | 3 mm | 7.01 mm | 0.276 in | 3 A | 0.203 Ám | 8 Áin | Gold or Gold GXT™ | ||||||||
 Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | Thermoplastic | 0.276 in | 7 mm | 3 mm | 0.118 in | 3 A | 0.203 Ám | 8 Áin | Gold or Gold GXT™ | 0.102 in | 2.6 mm | 0.496 in | 12.6 mm | ||||||
 Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | Thermoplastic | 0.228 in | 5.8 mm | 3.46 mm | 0.136 " | 3 A | 0.203 Ám | 8 Áin | Gold or Gold GXT™ | 0.102 in | 2.6 mm | 0.469 in | 11.9 mm | -55 °C | 125 °C | ||||
Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole Right Angle | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | 0.1 in | 2.54 mm | Thermoplastic | 0.276 in | 7 mm | 3 mm | 0.118 in | 3 A | 0.203 Ám | 8 Áin | Gold or Gold GXT™ | ||||||||
Amphenol ICC (FCI) | Solder | Push-Pull | 1000 VDC | 1 | UL94 V-0 | Square | Through Hole | Copper Alloy | Breakaway Header | 8 | 0.1 in | 2.54 mm | Male Pin | Unshrouded | All | Thermoplastic | 2.84 mm | 0.112 in | 3 A | 0.203 Ám | 8 Áin | Gold or Gold GXT™ | 0.102 in | 2.6 mm | -55 °C | 125 °C | 0.613 in | 15.57 mm |
