NPPC342 Series

Catalog

CONN HDR 68POS 0.1 GOLD SMD

Part	Insulation Material	Contact Shape	Contact Finish Thickness - Post	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Features	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish - Mating	Current Rating (Amps)	Contact Type	Contact Finish - Post	Number of Rows [custom]	Contact Finish Thickness - Mating	Number of Positions	Voltage Rating	Insulation Height [z]	Insulation Height	Mounting Type	Insulation Color	Termination	Connector Type	Fastening Type	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Number of Positions Loaded
Sullins Connector Solutions NPPC342KFMP-RC	Nylon 6T Polyamide (PA6T)	Square	Flash	Phosphor Bronze	125 °C	-40 C	Board Guide	0.1 in	2.54 mm	Gold	3 A	Female Socket	Gold	2	Flash	68 positions	250 V	0.299 "	7.6 mm	Surface Mount	Black	Solder	Header	Push-Pull	0.1 "	2.54 mm	UL94 V-0	All
Sullins Connector Solutions NPPC342KFMS-RC	Nylon 6T Polyamide (PA6T)	Square	Flash	Phosphor Bronze	125 °C	-40 C		0.1 in	2.54 mm	Gold	3 A	Female Socket	Gold	2	Flash	68 positions	250 V	0.299 "	7.6 mm	Surface Mount	Black	Solder	Header	Push-Pull	0.1 "	2.54 mm	UL94 V-0	All
