857-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 82POS 0.156
| Part | Read Out | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Termination | Pitch | Pitch | Material - Insulation | Number of Positions | Contact Finish | Termination Rows | Contact Material | Contact Type | Color | Card Thickness [Max] | Card Thickness [Min] | Card Type | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Mounting Type | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Dual | 41 | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 82 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Female | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | Right Angle Through Hole | 2 | |||
 EDAC Inc. | Dual | 41 | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 82 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Female | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 2 | |||
 EDAC Inc. | Dual | 41 | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 82 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Female | 125 °C | -40 C | Side Mount Opening Unthreaded | Through Hole | 2 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Single | 41 | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 41 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Female | 125 °C | -40 C | Through Hole | 1 | ||||
 EDAC Inc. | Single | 41 | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 41 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Through Hole | 0.128 " | 3.25 mm | 1 | |
 EDAC Inc. | Single | 41 | Solder | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 41 | Tin | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Right Angle Through Hole | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | Dual | 41 | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 82 | Gold | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Through Hole | 2 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Single | 41 | Solder Eyelet(s) | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 41 | Tin | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Female | 125 °C | -40 C | Through Hole | 1 | ||||||
 EDAC Inc. | Single | 41 | Solder | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 41 | Tin | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Female | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 1 | |||||
 EDAC Inc. | Dual | 41 | Solder Eyelet(s) | 3.96 mm | 0.156 in | Polyphenylene Sulfide (PPS) | 82 | Tin | 1 | Copper Alloy | Semi Bellows | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Through Hole | 2 | 0.156 " | 3.96 mm |
