3260H Series

Catalog

TRIMMER 50 OHM 0.25W PC PIN SIDE

Part	Adjustment Type	Resistive Material	Number of Turns	Resistance	Mounting Type	Tolerance	Power (Watts)	Power (Watts)	Temperature Coefficient	Termination Style	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]
Bourns Inc. 3260H-1-500	Side Adjustment	Wirewound	11	50 Ohms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-101	Side Adjustment	Wirewound	11	100 Ohms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-201	Side Adjustment	Wirewound	11	200 Ohms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-202	Side Adjustment	Wirewound	11	2 kOhms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-103	Side Adjustment	Wirewound	11	10000 Ohms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-102	Side Adjustment	Wirewound	11	1000 Ohms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-502	Side Adjustment	Wirewound	11	5 kOhms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
Bourns Inc. 3260H-1-203	Side Adjustment	Wirewound	11	20 kOhms	Through Hole	5 %	0.25 W	0.25 W	70 ppm/°C	PC Pins	4.32 mm	0.17 in	0.25 in	6.35 mm
