FX2ELQ Series

Catalog

OM3 2F 1.6MM LSZH PP LC/SC DUP

Part	Return Loss	Jacket (Insulation) Material	Bend Radius [radius]	Operating Temperature [Min]	Operating Temperature [Max]	Length - Overall [x]	Length - Overall [x]	2nd Connector	Cable Diameter [diameter]	Cable Diameter [diameter]	Type	1st Connector	Length - Overall [custom]	Length - Overall [custom]	Length - Overall	Length - Overall
Panduit Corp FX2ELQ1SNSNM1.5	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	1.5 m	4.9 ft	SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
Panduit Corp FX2ELQ1Q1SNM020	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C			LC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex	65.6 ft	20 m
Panduit Corp FX2ELQ1Q1SNM7.5	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C			LC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex			24.6 ft	7.5 m
Panduit Corp FX2ELQ1Q1SNM019	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	19 m	62.3 ft	LC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
Panduit Corp FX2ELQ1SNSNM001	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	1 m	3.3 ft	SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
Panduit Corp FX2ELQ1SNSNM009	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C			SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex			29.5 ft	9 m
Panduit Corp FX2ELQ1SNSNM034	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	34 m	111.5 ft	SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
Panduit Corp FX2ELQ1SNSNM012	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	12 m	39.4 ft	SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
Panduit Corp FX2ELQ1SNSNM011	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C			SC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex			36.1 ft	11 m
Panduit Corp FX2ELQ1Q1SNM005	26 dB	Low Smoke Zero Halogen (LSZH)	16 mm	-10 °C	60 °C	4 m	13.1 ft	LC Duplex	1.6 mm	0.06 in	Duplex Multimode OM3	LC Duplex
