345-024 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 24POS 0.100
...
| Part | Number of Positions/Bay/Row [custom] | Contact Material | Number of Rows | Read Out | Gender | Contact Finish | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Material - Insulation | Termination Rows | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Pitch [x] | Pitch [x] | Operating Temperature [Min] | Operating Temperature [Max] | Color | Number of Positions | Card Type | Features | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 24 | Copper Alloy | 1 | Single | Female | Gold | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 1 | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Single Edge | |||
 EDAC Inc. | 12 | Copper Alloy | 2 | Dual | Female | Gold | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Dual Edge | |||||
 EDAC Inc. | 12 | Copper Alloy | 2 | Dual | Female | Gold | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Dual Edge | Card Guides | ||||
 EDAC Inc. | 24 | Copper Alloy | 1 | Single | Female | Gold | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 1 | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Single Edge | |||
 EDAC Inc. | 24 | Copper Alloy | 1 | Single | Female | Gold | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 1 | M3 Threaded Insert Top Mount Opening | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Single Edge | |||||
 EDAC Inc. | 24 | Copper Alloy | 1 | Single | Female | Gold | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 1 | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Single Edge | |||
 EDAC Inc. | 24 | Copper Alloy | 1 | Single | Female | Gold | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 1 | Side Mount Opening Unthreaded | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Single Edge | 3.25 mm | 0.128 in | |||
 EDAC Inc. | 12 | Copper Alloy | 2 | Dual | Female | Gold | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 2 | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Board Edge Straddle Mount | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Dual Edge | Card Extender | ||
 EDAC Inc. | 12 | Copper Alloy | 2 | Dual | Female | Gold | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 2 | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Through Hole | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Dual Edge | |||
 EDAC Inc. | 12 | Copper Alloy | 2 | Dual | Female | Gold | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | 2 | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | Through Hole Right Angle | 10 Áin | 0.25 Ám | Cantilever | 2.54 mm | 0.1 in | -40 °C | 105 ░C | Green | 24 | Non Specified - Dual Edge |
