4412 Series

Catalog

FAN AXIAL 119X38MM 12VDC WIRE

Part	Voltage Range [Min]	Voltage Range [Max]	Material - Frame	Material - Blade	Lifetime @ Temp.	Current Rating (Amps)	RPM	Weight	Weight	Power (Watts)	Size / Dimension	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Min]	Operating Temperature [Max]	Bearing Type	Termination	Noise	Voltage - Rated	Width [y]	Features	Fan Type	Static Pressure	Static Pressure	Air Flow	Air Flow	Approval Agency	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Weight [custom]	Weight [custom]	Lifetime @ Temp.
ebm-papst Inc. 4412/2H	7 V	14 V	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	57500 Hrs	0.72 A	4300 RPM	0.604 lb	273.97 g	8.6 W	Square	119 mm	119 mm	-20 ░C	70 °C	Ball	3 Wire Leads	50 dB(A)	12 VDC	38 mm	Auto Restart Locked Rotor Protection Speed Sensor (Tach)	Tubeaxial	160 Pa	0.64 in H2O	3.95 m³/min	141 CFM
ebm-papst Inc. 4412FGM	7 V	12.6 VDC	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs		2400 RPM	0.386 lb	175.09 g	3.2 W	Square	119 mm	119 mm	-20 ░C	70 °C	Sintec	2 Wire Leads	38 dB(A)	12 VDC	25.4 mm		Tubeaxial			2.31 m³/min	82.4 CFM	CE CSA UL VDE
ebm-papst Inc. 4412ML	7 V	15 V	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	67500 Hrs		3000 RPM	0.604 lb	273.97 g	3 W	Square	119 mm	119 mm	-20 ░C	80 °C	Ball	2 Wire Leads	40 dB(A) 46 dB(A)	12 VDC	38 mm		Tubeaxial			2.77 m³/min	99 CFM		IP54 - Dust Protected Water Resistant
ebm-papst Inc. 4412F/2M	8 V	12.6 VDC	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	40 °C 60000 Hrs		2900 RPM	0.386 lb	175.09 g	5.3 W	Square	119 mm	119 mm	-20 ░C	60 °C	Ball	3 Wire Leads	43 dB	12 VDC	25.4 mm	Speed Sensor (Tach)	Tubeaxial			2.8 m³/min	100.1 CFM	CE CSA UL VDE		60 °C	-4 °F
ebm-papst Inc. 4412FNH	9 V	13.2 VDC	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	40 °C 60000 Hrs		5400 RPM	0.529 lb	239.95 g	12 W	Square	119 mm	119 mm	-20 ░C	70 °C	Ball	2 Wire Leads	55 dB(A)	12 VDC	25.4 mm		Tubeaxial			3.71 mł/min	132.5 CFM
ebm-papst Inc. 4412FMD	7 V	14 V	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced						3.2 W	Square	119 mm	119 mm			Ball	2 Wire Leads	38 dB(A)	12 VDC	25.4 mm		Tubeaxial			2.3 m³/min	82 CFM	CE CSA UL VDE				172.37 g	0.38 lb
ebm-papst Inc. 4412F/39M	7 V	12.6 VDC	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced		270 mA	2400 RPM			3.2 W	Square	119 mm	119 mm	-4 °F	167 °F	Ball	3 Wire Leads	38 dB(A)	12 VDC	25.4 mm		Tubeaxial	44.8 Pa	0.18 in H2O	2.8 m³/min	100 CFM	CE CSA EAC UL VDE						Varies Based on Temperature
ebm-papst Inc. 4412M	7 V	14 V	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT) Fiberglass Reinforced	65000 Hrs		3300 RPM	0.553 lb	250.84 g	3.8 W	Square	119 mm	119 mm	-4 °F	167 °F	Ball	2 Wire Leads	42 dB	12 VDC	38 mm		Tubeaxial			3.02 m³/min	108 CFM
ebm-papst Inc. 4412/12M	7 V	14 V	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	65000 Hrs		3300 RPM	0.553 lb	250.84 g	4.1 W	Square	119 mm	119 mm	-4 °F	167 °F	Ball	3 Wire Leads	42 dB	12 VDC	38 mm	Locked Rotor Protection Speed Sensor (Tach)	Tubeaxial			3.02 m³/min	108 CFM
ebm-papst Inc. 4412F/2	8 V	12.6 VDC	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	Polyamide (PA) Nylon Fiberglass Reinforced	40 °C 60000 Hrs		2900 RPM	0.386 lb	175.09 g	5.3 W	Square	119 mm	119 mm	-20 ░C	60 °C	Ball	3 Wire Leads	43 dB	12 VDC	25.4 mm	Speed Sensor (Tach)	Tubeaxial			2.8 m³/min	100 CFM			60 °C	-4 °F
