346-028 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FMALE 28POS 0.125
...
| Part | Contact Finish | Number of Positions | Mounting Type | Contact Type | Termination | Material - Insulation | Color | Number of Rows | Number of Positions/Bay/Row [custom] | Read Out | Card Type | Termination Rows | Contact Material | Flange Feature | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Pitch [x] | Pitch [x] | Gender | Contact Finish Thickness | Contact Finish Thickness | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 1 | 28 | Single | Non Specified - Single Edge | 1 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Wire Wrap | Polyester Thermoplastic | Green | 1 | 28 | Single | Non Specified - Single Edge | 1 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | Card Guides | ||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 1 | 28 | Single | Non Specified - Single Edge | 1 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 2 | 14 | Dual | Non Specified - Dual Edge | 2 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 2 | 14 | Dual | Non Specified - Dual Edge | 2 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | Card Guides | ||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Wire Wrap | Polyester Thermoplastic | Green | 2 | 14 | Dual | Non Specified - Dual Edge | 2 | Copper Alloy | Floating Bobbin Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | 2.95 mm | 0.116 in | |
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 2 | 14 | Dual | Non Specified - Dual Edge | 2 | Copper Alloy | Top Mount Opening Unthreaded | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | 3.96 mm | 0.156 in | |
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 1 | 28 | Single | Non Specified - Single Edge | 1 | Copper Alloy | Flush Mount Top Opening Unthreaded | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " | |
 EDAC Inc. | Gold | 28 | Through Hole Right Angle | Cantilever | Solder Wire Wrap | Polyester Thermoplastic | Green | 1 | 28 | Single | Non Specified - Single Edge | 1 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám | Card Guides | ||
 EDAC Inc. | Gold | 28 | Through Hole | Cantilever | Solder | Polyester Thermoplastic | Green | 2 | 14 | Dual | Non Specified - Dual Edge | 2 | Copper Alloy | M3 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Female | 10 Áin | 0.25 Ám |
