PS0S Series
Manufacturer: TE Connectivity Corcom Filters
Beta
⌘K
PWR ENT MOD RCPT IEC320-C14 PNL
| Part | Features | Accomodates a Fuse | Voltage Rating - Appliance Inlet | Mounting Type | Current Rating - Appliance Inlet | Panel Thickness [Min] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Max] | Fuse Holder, Drawer | Termination | Termination | Termination | Filter Type | Connector Style | Current Rating - Filter | Switch Features | Connector Type | Approval Agency | Panel Cutout Dimensions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Corcom Filters | Voltage Selector | 120 VAC | Panel Mount Snap-In | 10 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Twin Fused | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 10 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Conversion Clip | 120 VAC | Panel Mount Snap-In | 10 A | 0.79 mm | 2.11 mm | 0.031 " | 0.083 " | Fuse Holder | Quick Connect | 0.187 " | 4.7 mm | Unfiltered - Commercial | IEC 320-C14 | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | ||
 TE Connectivity Corcom Filters | Conversion Clip Shielded | 120 VAC | Panel Mount Snap-In | 3 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Fuse Holder | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 3 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | 120 VAC 250 VAC | Panel Mount Snap-In | 10 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Twin Fused | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial Medical | IEC 320-C14 | 10 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | ||
 TE Connectivity Corcom Filters | Shielded | 120 VAC | Panel Mount Snap-In | 3 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Twin Fused | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial Medical | IEC 320-C14 | 3 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Conversion Clip Shielded Voltage Selector | 120 VAC | Panel Mount Snap-In | 6 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Fuse Holder | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 6 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Conversion Clip Voltage Selector | 120 VAC | Panel Mount Snap-In | 10 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Fuse Holder | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 10 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Conversion Clip | 120 VAC | Panel Mount Snap-In | 10 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Fuse Holder | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 10 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Shielded Voltage Selector | 120 VAC | Panel Mount Snap-In | 6 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Twin Fused | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial Medical | IEC 320-C14 | 6 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size | |
 TE Connectivity Corcom Filters | Shielded Voltage Selector | 120 VAC | Panel Mount Snap-In | 3 A | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Twin Fused | Quick Connect | 0.187 " | 4.7 mm | Filtered (EMI RFI) - Commercial | IEC 320-C14 | 3 A | Switch On-Off | Receptacle Male Blades - Module | CSA UL VDE | Variable Size |
