395-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 43POS 0.100
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Color | Card Type | Mounting Type | Number of Positions | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Gender | Number of Rows | Contact Material | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | Gold | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Right Angle Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Gold | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Gold | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | Gold | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | Gold | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Gold | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Black | Non Specified - Single Edge | Through Hole | 43 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | -40 C | 105 ░C | 43 | Female | 1 | Copper Alloy | Solder | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Gold | Side Mount Opening Unthreaded |
