8155 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 50COND 28AWG
| Part | Shield Coverage | Shield Material | Operating Temperature [Max] | Operating Temperature [Min] | Shield Type | Usage | Conductor Insulation | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Jacket Color | Cable Type | Length [x] | Length [x] | Ratings | Number of Conductors | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Features | Jacket (Insulation) Material | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | 80 °C | -30 ░C | Braid Foil | Computer | Foam Polyethylene (FPE) | 28 AWG | 7 | 36 AWG | 14.35 mm | 0.565 " | Copper Tinned | Chrome | Multi-Pair | 100 ft | 30.5 m | UL Style 2919 | 50 | 0.044 in | 1.118 mm | Drain Wire | Poly-Vinyl Chloride (PVC) | ||
Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | 80 °C | -30 ░C | Braid Foil | Computer | Foam Polyethylene (FPE) | 28 AWG | 7 | 36 AWG | 14.35 mm | 0.565 " | Copper Tinned | Chrome | Multi-Pair | UL Style 2919 | 50 | 0.044 in | 1.118 mm | Drain Wire | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | ||
Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | 80 °C | -30 ░C | Braid Foil | Computer | Foam Polyethylene (FPE) | 28 AWG | 7 | 36 AWG | 14.35 mm | 0.565 " | Copper Tinned | Chrome | Multi-Pair | UL Style 2919 | 50 | 0.044 in | 1.118 mm | Drain Wire | Poly-Vinyl Chloride (PVC) | 152.4 m | 500 ft |
