807-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 21POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row [custom] | Termination | Contact Finish | Card Type | Mounting Type | Contact Type | Read Out | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Contact Material | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Tin | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Wire Wrap | Tin | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Tin | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Gold | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Gold | Non Specified - Dual Edge | Right Angle Through Hole | Semi Bellows | Dual | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | 2 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Tin | Non Specified - Single Edge | Right Angle Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Gold | Non Specified - Single Edge | Right Angle Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Gold | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Wire Wrap | Tin | Non Specified - Single Edge | Through Hole | Semi Bellows | Single | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 21 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 21 | Solder | Tin | Non Specified - Dual Edge | Right Angle Through Hole | Semi Bellows | Dual | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Copper Alloy | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 2 |
