MAX8559 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC REG LINEAR 3V/3V 8TDFN

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Control Features	PSRR [Max]	PSRR [Min]	Output Configuration	Current - Quiescent (Iq)	Package / Case	Supplier Device Package	Number of Regulators	Voltage Dropout (Max) [Max]	Protection Features	Output Type	Current - Supply (Max) [Max]	Voltage Dropout (Max)	Voltage - Output (Min/Fixed) [Min]	Voltage - Output (Min/Fixed) [Max]
Analog Devices Inc./Maxim Integrated MAX8559ETAGG+T	Surface Mount	85 °C	-40 °C	6.5 V	3 V	3 V	Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm
Analog Devices Inc./Maxim Integrated MAX8559ETAJ1+T	Surface Mount	85 °C	-40 °C	6.5 V	2.85 V	1.85 V	Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm
Analog Devices Inc./Maxim Integrated MAX8559ETAM1+	Surface Mount	85 °C	-40 °C	5.5 V	2.7 V	1.85 V	Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm	220 µA	-
Analog Devices Inc./Maxim Integrated MAX8559ETAJJ+	Surface Mount	85 °C	-40 °C	6.5 V			Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN-EP (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm			2.85 V	2.85 V
Analog Devices Inc./Maxim Integrated MAX8559EBA11+T	Surface Mount	85 °C	-40 °C	6.5 V	1.85 V		Enable	70 dB	54 dB	Positive	290 µA	8-WFBGA CSPBGA	8-UCSP (2.02x1.02)	2		Over Current Over Temperature Short Circuit	1.81 mOhm		- -	1.85 V
Analog Devices Inc./Maxim Integrated MAX8559ETAJG+T	Surface Mount	85 °C	-40 °C	6.5 V	2.85 V 3 V		Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm
Analog Devices Inc./Maxim Integrated MAX8559ETAJG+	Surface Mount	85 °C	-40 °C	6.5 V	2.85 V 3 V		Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN-EP (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm
Analog Devices Inc./Maxim Integrated MAX8559ETAJJ+T	Surface Mount	85 °C	-40 °C	6.5 V			Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm			2.85 V	2.85 V
Analog Devices Inc./Maxim Integrated MAX8559ETA8A+T	Surface Mount	85 °C	-40 °C	6.5 V	1.5 V 3.3 V		Enable	70 dB	54 dB	Positive	290 µA	8-WDFN Exposed Pad	8-TDFN (3x3)	2	0.12 V	Over Current Over Temperature Short Circuit	1.81 mOhm		-
Analog Devices Inc./Maxim Integrated MAX8559EBA22+T	Surface Mount	85 °C	-40 °C	6.5 V	1.8 V		Enable	70 dB	54 dB	Positive	290 µA	8-WFBGA CSPBGA	8-UCSP (2.02x1.02)	2		Over Current Over Temperature Short Circuit	1.81 mOhm		- -	1.8 V
