047553 Series
Manufacturer: Molex
Beta
⌘K
CONN SIM CARD PUSH-PUSH R/A SMD
| Part | Number of Positions | Contact Finish | Features | Mounting Type | Mounting Feature | Height Above Board | Height Above Board | Contact Finish Thickness | Contact Finish Thickness | Connector Type | Insertion, Removal Method | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 8 (6 + 2) | Gold | Board Guide Switch | Surface Mount Right Angle | Normal Standard - Top | 1.8 mm | 0.071 in | 15 µin | 0.38 µm | Connector and Ejector | Push In Push Out | SIM Card |
 Molex | 8 (6 + 2) | Gold | Switch | Surface Mount Right Angle | Normal Standard - Top | 1.8 mm | 0.071 in | 15 µin | 0.38 µm | Connector and Ejector | Push In Push Out | SIM Card |
 Molex | 8 (6 + 2) | Gold | Board Guide Switch | Surface Mount Right Angle | Normal Standard - Top | 1.8 mm | 0.071 in | 30 Áin | 0.76 Ám | Connector and Ejector | Push In Push Out | SIM Card |
