RER-M2 Series
Manufacturer: Dinkle Corporation, USA
Beta
⌘K
RELAY GEN PURPOSE SPDT 5A 120V
| Part | Must Release Voltage | Coil Resistance | Release Time | Operate Time | Switching Voltage [Max] | Features | Coil Current | Relay Type | Coil Voltage | Mounting Type | Coil Type | Must Operate Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Rating (Current) | Contact Form | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Dinkle Corporation, USA | 36 VAC | 4.43 kOhms | 20 ms | 20 ms | 30 VDC 250 VAC | Lighted Indicator | 9.2 mA | General Purpose | 120 VAC | Socketable | Non Latching | 96 VAC | -55 C | 70 °C | 5 A | DPDT (2 Form C) | Silver Nickel (AgNi) |
 Dinkle Corporation, USA | 2.4 VDC | 640 Ohms | 20 ms | 20 ms | 30 VDC 250 VAC | Lighted Indicator | 36.9 mA | General Purpose | 24 VDC | Socketable | Non Latching | 18 VDC | -55 C | 70 °C | 5 A | DPDT (2 Form C) | Silver Nickel (AgNi) |
 Dinkle Corporation, USA | 69 VAC | 4.43 kOhms | 20 ms | 20 ms | 30 VDC 250 VAC | Lighted Indicator | 5.5 mA | General Purpose | 230 VAC | Socketable | Non Latching | 184 VAC | -55 C | 70 °C | 5 A | DPDT (2 Form C) | Silver Nickel (AgNi) |
