PT6641 Series

Catalog

DC DC CONVERTER -3.3V

Part	Voltage - Output 1	Mounting Type	Number of Outputs	Voltage - Input (Min) [Min]	Package / Case	Applications	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Type	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
Texas Instruments PT6641D	-3.3 V	Through Hole Right Angle	1	8 V	14-SIP Module	ITE (Commercial)	27 V	4 A	Non-Isolated PoL Module	77 %	85 °C	-40 °C
Texas Instruments PT6641E	-3.3 V	Surface Mount	1	8 V	14-SMD Module	ITE (Commercial)	27 V	4 A	Non-Isolated PoL Module	77 %	85 °C	-40 °C	1.71 "	10.7 mm	31 mm	0.42 in	43.4 mm	1.22 "
Texas Instruments PT6641P	-3.3 V	Through Hole	1	8 V	14-SIP Module	ITE (Commercial)	27 V	4 A	Non-Isolated PoL Module	77 %	85 °C	-40 °C
