FASTIN-FASTON 250 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

FF 250 REC 4-6MM2 PTBR

...

Part	Wire Gauge [Max]	Wire Gauge [Min]	Gender	Tab Thickness	Tab Thickness	Contact Finish	Mounting Type	Insulation Diameter [Max]	Insulation Diameter [Max]	Insulation Diameter [Min]	Insulation Diameter [Min]	Tab Width	Tab Width	Tab Length	Tab Length	Terminal Type	Length - Overall [x]	Length - Overall [x]	Contact Material	Insulation	Termination	Length - Overall	Length - Overall	Tab Length	For Use With/Related Products	For Use With/Related Products	For Use With/Related Products	Note	Color	Number of Positions	Stacking Direction	Style	Material	Terminal Size	Terminal Size	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]
TE Connectivity Raychem Cable Protection 180351-8	12 AWG	10 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)	5.1 mm	0.201 in	0.134 in	3.4 mm	6.35 mm	0.25 in	0.303 in	7.7 mm	Standard	19 mm	0.748 "	Brass	Non-Insulated	Crimp
TE Connectivity Raychem Cable Protection 42663-2	16 AWG	12 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)					7.92 mm	0.312 in		0.38 in	Standard			Brass	Non-Insulated	Crimp	23.24 mm	0.915 in	9.65 mm
TE Connectivity Raychem Cable Protection 160458-2	18 AWG	14 AWG	Male	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)	0.161 " 4.09 mm			0.122 " 3.1 mm	6.35 mm	0.25 in			Standard			Phosphor Bronze	Non-Insulated	Crimp
TE Connectivity Raychem Cable Protection 172130-4			Female Receptacle				Free Hanging (In-Line)									Disconnect Quick Connect									0.25 in	Quick Connects	6.35 mm	Contacts Not Included	Green	2	Perpendicular	Housing	Nylon	6.35 mm	0.25 in
TE Connectivity Raychem Cable Protection 5-160446-5	17 AWG	14 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)	4.09 mm	0.161 in	0.118 in	3 mm	6.35 mm	0.25 in		0.305 in	Standard	19.2 mm	0.756 in	Brass	Non-Insulated	Crimp			7.75 mm
TE Connectivity Raychem Cable Protection 1-293041-2	28 AWG	17 AWG	Male	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)					6.35 mm	0.25 in	0.618 in	15.7 mm	Standard	27 mm	1.063 in	Brass	Non-Insulated	Crimp
TE Connectivity Raychem Cable Protection 172130-7
TE Connectivity Raychem Cable Protection 5-160446-2	17 AWG	14 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)	4.09 mm	0.161 in	0.118 in	3 mm	6.35 mm	0.25 in		0.305 in	Standard	19.2 mm	0.756 in	Phosphor Bronze	Non-Insulated	Crimp			7.75 mm
TE Connectivity Raychem Cable Protection 62891-1	16 AWG	12 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)					6.35 mm	0.25 in		0.305 in	Standard		0.75 in	Brass	Non-Insulated	Crimp	19.05 mm		7.75 mm												4.83 mm	3.81 mm	0.15 "	0.19 "
TE Connectivity Raychem Cable Protection 160917-4	17 AWG	14 AWG	Female	0.032 in	0.81 mm	Tin	Free Hanging (In-Line)	3.1 mm	0.122 "	0.083 "	2.11 mm	6.35 mm	0.25 in			Standard	19.2 mm	0.756 in	Phosphor Bronze	Non-Insulated	Crimp
