SIT3921 Series

Manufacturer: SiTime

Catalog

MEMS OSC DCXO 125.0000MHZ LVDS

Part	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)	Current - Supply (Max) [Max]	Output	Mounting Type	Base Resonator	Voltage - Supply	Type	Package / Case	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Supplier Device Package [x]	Supplier Device Package	Supplier Device Package [y]	Frequency	Frequency Stability	Absolute Pull Range (APR)	Size / Dimension [y]	Height - Seated (Max) [Max]
SiTime SIT3921AC-2CF-33NZ125.000000X	-20 ░C	70 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	125 MHz	10 ppm
SiTime SIT3921AI-2CF-33NZ125.000000X	-40 C	85 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	125 MHz	10 ppm	1600 ppm
SiTime SIT3921AI-2C2-25NZ125.000000T	-40 C	85 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	2.5 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	125 MHz	25 ppm
SiTime SIT3921AI-2CF-33NZ148.425824Y	-40 C	85 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	148.425824 MHz	10 ppm
SiTime SIT3921AC-2CF-33NZ125.000000Y	-20 ░C	70 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	125 MHz	10 ppm
SiTime SIT3921AC-2C2-33NB200.000000T	-20 ░C	70 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	200 MHz	25 ppm
SiTime SIT3921AI-2C2-25NY74.250000T	-40 C	85 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	2.5 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	74.25 MHz	25 ppm
SiTime SIT3921AC-2DF-33NZ12.000000Y	-20 ░C	70 °C	0.039 in		55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead		0.197 "	7 mm	0.276 "		6-SMD (7x5)		12 MHz	10 ppm		5 mm	1 mm
SiTime SIT3921AC-2C3-33NZ27.000000T	-20 ░C	70 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead	3.2 mm	0.126 in	5 mm	0.197 in	5	6-SMD	3.2	27 MHz	50 ppm
SiTime SIT3921AC-2B2-33NH24.000000T	-20 ░C	70 °C	0.031 in	0.8 mm	55 mA	LVDS	Surface Mount	MEMS	3.3 V	DCXO	6-SMD No Lead		0.098 in	3.2 mm	0.126 "	3.2	6-SMD	2.5	24 MHz	25 ppm		2.5 mm
