LDEEB Series

Manufacturer: KEMET

Catalog

CAP FILM 0.027UF 10% 100VDC 1210

Part	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Dielectric Material	Features	Capacitance	Voltage Rating - DC	Tolerance	Applications	Ratings	Termination	Voltage Rating - AC	Package / Case	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET LDEEB2270KA0N00	Surface Mount	3.3 mm	2.5 mm	0.13 "	0.098 in	Metallized - Stacked Polyester Polyethylene Naphthalate (PEN)	High Temperature	0.027 µF	100 V	10 %	Automotive	AEC-Q200	Solder Pads	63 V	1210	3225 Metric	0.067 in	1.7 mm	-55 C	125 °C
KEMET LDEEB2330KA0N00	Surface Mount	3.3 mm	2.5 mm	0.13 "	0.098 in	Metallized - Stacked Polyester Polyethylene Naphthalate (PEN)	High Temperature	0.033 çF	100 V	10 %	Automotive	AEC-Q200	Solder Pads	63 V	1210	3225 Metric		0.079 in	-55 C	125 °C	2 mm
KEMET LDEEB2220JA0N00	Surface Mount	3.3 mm	2.5 mm	0.13 "	0.098 in	Metallized - Stacked Polyester Polyethylene Naphthalate (PEN)	High Temperature	0.022 µF	100 V	5 %	Automotive	AEC-Q200	Solder Pads	63 V	1210	3225 Metric	0.059 "		-55 C	125 °C		1.5 mm
KEMET LDEEB2470JA0N00	Surface Mount	3.3 mm	2.5 mm	0.13 "	0.098 in	Metallized - Stacked Polyester Polyethylene Naphthalate (PEN)	High Temperature		100 V	5 %	Automotive	AEC-Q200	Solder Pads	63 V	1210	3225 Metric			-55 C	125 °C			2.1 mm	0.083 in
