09330162 Series
Manufacturer: HARTING Technology Group
Beta
⌘K
HEAVY DUTY CONNECTOR, 16+PE SIGNAL, UL508, HAN E SERIES, INSERT, 16 CONTACTS, 16B, PLUG, SCREW PIN
| Part | Termination Style | Contact Finish | Housing Material | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Size | Material Flammability Rating | Current Rating (Amps) | Color | Gender | Number of Positions | Connector Type | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING Technology Group | Screw | Silver | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | Copper Alloy | 32 B | UL94 V-0 | 16 A | Gray | Male | 16+Ground | ||
 HARTING Technology Group | Push In | Silver | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | Copper Alloy | 16 B | UL94 V-0 | 16 A | Gray | Female | 16+Ground | ||
 HARTING Technology Group | Push In | Silver | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | Copper Alloy | 16 B | UL94 V-0 | 16 A | Gray | Male | 16+Ground | ||
 HARTING Technology Group | Push In | Silver | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | Copper Alloy | 16 B | UL94 V-0 | 16 A | Gray | Male | 16+Ground | ||
 HARTING Technology Group | Crimp | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | 32 B | UL94 V-0 | 16 A | Gray | Male | 16+Ground | Insert without Contacts | Han® | ||
 HARTING Technology Group | Push In | Female | 16 | ||||||||||||
 HARTING Technology Group | Crimp | Polycarbonate (PC) | 600 V | 125 °C | -40 °C | 32 B | UL94 V-0 | 16 A | Gray | Female | 16+Ground | Insert without Contacts | Han® | ||
 HARTING Technology Group | Tension Clamp | Silver | Polycarbonate (PC) | 500 V | 125 °C | -40 °C | Copper Alloy | 32 B | UL94 V-0 | 16 A | Gray | Female | |||
 HARTING Technology Group | Screw | Polycarbonate (PC) | 250 VDC | 125 °C | -40 °C | 16 B | UL94 V-0 | 16 A | Gray | Female | 16 | ||||
 HARTING Technology Group | Tension Clamp | Silver | Polycarbonate (PC) | 500 V | 125 °C | -40 °C | Copper Alloy | 16 B | UL94 V-0 | 16 A | Gray | Female | 12+Ground |
