T30SP6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
SPLICE,CE 22-16 ROHS COMPLIANT: YES
| Part | Ingress Protection | Output Configuration | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Response Time | Connection Method | Sensing Method | Light Source | Operating Temperature [Max] | Operating Temperature [Min] | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | PNP - Dark-ON/Light-ON | 10 VDC | 30 VDC | 23.622 " | 60 cm | 3 ms | Connector | Reflective | LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | PNP - Dark-ON/Light-ON | 10 VDC | 30 VDC | 15.748 in | 40 cm | 3 ms | Connector | Reflective | LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IP69K NEMA 6P | Light-On/Dark-On | 10 VDC | 30 VDC | 23.622 " | 60 cm | 3 ms | Connector | Background Suppression | Infrared LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | PNP - Dark-ON/Light-ON | 10 VDC | 30 VDC | 236.22 " | 6 m | 3 ms | Connector | Polarized Retroreflective | Red LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | PNP - Dark-ON/Light-ON | 10 VDC | 30 VDC | 7.874 in | 200 mm | 3 ms | Connector | Reflective | LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IP69K NEMA 6P | PNP | 10 VDC | 30 VDC | 196.85 ft | 60 m | 3 ms | Connector | Through-Beam | LED | 70 °C | -40 C | ||
 BANNER ENGINEERING | IEC IP67 NEMA 6P | PNP - Dark-ON/Light-ON - Selectable | 10 VDC | 30 VDC | 236.22 " | 6 m | 3 ms | Cable | Polarized Retroreflective | Red LED | 70 °C | -40 C | 78.74 " | 2 m |
