807-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 44POS 0.156
| Part | Flange Feature | Number of Rows | Contact Type | Termination | Material - Insulation | Mounting Type | Number of Positions/Bay/Row | Gender | Color | Contact Material | Contact Finish | Card Type | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Right Angle Through Hole | 44 | Female | Green | Copper Alloy | Tin | Non Specified - Single Edge | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Single | 125 °C | -40 C | 3.96 mm | 0.156 in | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | Semi Bellows | Wire Wrap | Diallyl Phthalate (DAP) | Through Hole | 22 | Female | Green | Copper Alloy | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 3.25 mm | 0.128 " | Card Extender | ||||
 EDAC Inc. | Side Mount Opening Unthreaded | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Through Hole | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 3.25 mm | 0.128 " | |||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Right Angle Through Hole | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Single | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 3.96 mm | 0.156 " | |||||
 EDAC Inc. | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | Card Extender | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | 1 | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Right Angle Through Hole | 44 | Female | Green | Copper Alloy | Gold | Non Specified - Single Edge | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Single | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 " | |||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Through Hole | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Through Hole | 22 | Female | Green | Copper Alloy | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 3.96 mm | 0.156 " | |||||
 EDAC Inc. | Semi Bellows | Solder | Diallyl Phthalate (DAP) | Through Hole | 22 | Female | Green | Copper Alloy | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 44 | Dual | 125 °C | -40 C | 3.96 mm | 0.156 in | 2 | 2 | 0.25 Ám | 10 Áin |
