A6X30144 Series

Manufacturer: Siemens

Catalog

INDICATOR LIGHT. RED

Part	Lens Transparency	Type	Lens Color	Ratings	Millicandela Rating [Min]	Millicandela Rating [Max]	Panel Cutout Shape	Lamp Color	Termination Style	Lens Size [diameter]	Lens Style	Panel Cutout Dimensions	Panel Cutout Dimensions	Voltage	Ingress Protection
Siemens A6X30144362	Diffused	LED	Red	AC/DC	450 mcd	1120 mcd	Round	Red	Screw Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	24 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144839	Diffused	LED	White	AC/DC	900 mcd	1400 mcd	Round	White	Screw Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	24 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144551	Diffused	LED	White	AC	900 mcd	1400 mcd	Round	White	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144841	Diffused	LED	White	AC/DC	900 mcd	1400 mcd	Round	White	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	24 V	IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144547	Diffused	LED	Yellow	AC	900 mcd	1400 mcd	Round	Yellow	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144557	Clear	LED	Colorless	AC	900 mcd	1400 mcd	Round	Clear	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144548	Diffused	LED	Yellow	AC	900 mcd	1400 mcd	Round	Yellow	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144364	Diffused	LED	Red	AC/DC	450 mcd	1120 mcd	Round	Red	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	24 V	IP20 IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144544	Diffused	LED	Red	AC	450 mcd	1120 mcd	Round	Red	Spring Terminal	22 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
Siemens A6X30144543	Diffused	LED	Red	AC			Round	Red		30 mm	Round with Flat Top	22.3 mm	0.88 in	230 V	IP66 IP67 IP69 IP69K NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 4X
