JF15AP1F Series
Manufacturer: NKK Switches
Beta
⌘K
TACTILE SWITCH, JF SERIES, TOP ACTUATED, THROUGH HOLE, SQUARE BUTTON, 300 GF, 50MA AT 24VDC
| Part | Mechanical Life | Switch Travel | Actuator Material | Actuator Orientation | Illumination | Circuit | Outline [x] | Outline [y] | Mounting Type | Operating Force | Termination Style | Illumination Type, Color | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Type | Actuator Height off PCB, Vertical [z] | Contact Rating @ Voltage | Features | Switch Function | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 500000 Cycles | 0.4 mm | Polyamide (PA) Nylon | Top Actuated | Illuminated | SPST-NO | 22.8 mm | 17.7 mm | Through Hole | 300 gf | PC Pin | Green LED | -25 °C | 70 °C | Square Button | 6.7 mm | 0.05 A 24 VDC | Process Sealed | Off-Mom | 2.1 VDC |
