8500 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-CONDUCTOR CABLES 20 AWG 7 CONDUCTOR 600V BRAID PVC PVC, 1000 FT SPOOL - BLACK
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Material | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Length | Length | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Insulation | Ratings | Jacket Color | Number of Conductors | Conductor Material | Shield Type | Cable Type | Length [x] | Length [x] | Conductor Strand |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Copper Tinned | 85 % | Poly-Vinyl Chloride (PVC) | 63 | 38 AWG | 20 AWG | 600 V | 1.016 mm | 0.04 in | 304.8 m | 1000 ft | 12.24 mm | 0.482 in | Poly-Vinyl Chloride (PVC) | UL Style 2587 | Black | 7 | Copper Bare | Braid | Multi-Conductor | |||
 ALPHA WIRE | Poly-Vinyl Chloride (PVC) | 63 | 38 AWG | 20 AWG | 600 V | 0.889 mm | 0.035 in | 9.53 mm | 0.375 in | Poly-Vinyl Chloride (PVC) | UL Style 2587 | Black | 4 | Copper Bare | Braid | Multi-Conductor | 100 ft | 30.5 m | |||||
 ALPHA WIRE | Poly-Vinyl Chloride (PVC) | 18 AWG | 600 V | 0.889 mm | 0.035 in | 304.8 m | 1000 ft | 6.91 mm | 0.272 in | Poly-Vinyl Chloride (PVC) | UL Style 2587 | Black | 3 | Copper Tinned | Multi-Conductor | 38 AWG 105 |
