RZE35 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.039
| Part | Material - Insulation | Contact Material | Number of Positions/Bay/Row | Number of Rows [custom] | Color | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Contact Type | Termination | Gender | Mounting Type | Contact Finish | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Card Thickness | Card Thickness | Features | Pitch | Pitch | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Phosphor Bronze | 35 | 2 | Black | -65 ░C | 125 °C | Dual | Hairpin Bellows | Solder | Female | Board Edge Straddle Mount | Gold | 70 | 0.25 Ám | 10 Áin | 1.57 mm | 0.062 in | Card Extender | 1 mm | 0.039 in | Non Specified - Dual Edge |
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Phosphor Bronze | 35 | 2 | Black | -65 ░C | 125 °C | Dual | Hairpin Bellows | Solder Staggered | Female | Through Hole | Gold | 70 | 0.25 Ám | 10 Áin | 1.57 mm | 0.062 in | 1 mm | 0.039 in | Non Specified - Dual Edge | |
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Phosphor Bronze | 35 | 2 | Black | -65 ░C | 125 °C | Dual | Hairpin Bellows | Solder | Female | Surface Mount | Gold | 70 | 0.25 Ám | 10 Áin | 1.57 mm | 0.062 in | Board Lock | 1 mm | 0.039 in | Non Specified - Dual Edge |
