NPF-120 Series

Catalog

LED DRIVER CC AC/DC 18-30V 4A

Part	Mounting Type	Termination Style	Features	Topology	Approval Agency	Ratings	Operating Temperature [Max]	Operating Temperature [Min]	Type	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Number of Outputs	Current - Output (Max) [Max]	Voltage - Isolation	Dimming	Power (Watts)	Voltage - Output [Min]	Voltage - Output [Max]	Efficiency	Standard Number
MEAN WELL USA Inc. NPF-120D-30	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	4 A	3750 VDC	Analog PWM	120 W
MEAN WELL USA Inc. NPF-120D-48	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	2.5 A	3750 VDC	Analog PWM	120 W	28.8 V	48 V	90 %
MEAN WELL USA Inc. NPF-120D-30BE	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	10 A	3750 VDC	Analog PWM	120 W	12 V	20 V	87.5 %	UL 8750
MEAN WELL USA Inc. NPF-120D-48BE	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	10 A	3750 VDC	Analog PWM	120 W	12 V	20 V	87.5 %	UL 8750
MEAN WELL USA Inc. NPF-120D-42	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	2.9 A	3750 VDC	Analog PWM	122 W	25.2	42 V
MEAN WELL USA Inc. NPF-120D-54	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	2.3 A	3750 VDC	Analog PWM	124 W	32.4 V	54 V	90 %
MEAN WELL USA Inc. NPF-120-42	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current Voltage	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	2.9 A	3750 VDC		122 W	25.2	42 V	90 %
MEAN WELL USA Inc. NPF-120D-36BE	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	10 A	3750 VDC	Analog PWM	120 W	12 V	20 V	87.5 %	UL 8750
MEAN WELL USA Inc. NPF-120-54	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current Voltage	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	2.3 A	3750 VDC		124 W	32.4 V	54 V	90.5 %
MEAN WELL USA Inc. NPF-120-15	Chassis Mount	Wire Leads	OCP OTP OVP SCP	AC DC Converter	CB CCC CE cURus ENEC	IP67	90 °C	-40 C	Constant Current Voltage	305 VAC	90 VAC	37.5 mm	191 mm	2.48 in	63 mm	7.52 in	1.48 "	1	8 A	3750 VDC		120 W	9 V	15 V	89 %
