M20-972 Series

Catalog

CONN, HEADER, 20POS, 2ROW, 2.54MM ROHS COMPLIANT: YES

Part	Mated Stacking Heights	Contact Finish - Mating	Connector Type	Insulation Color	Number of Positions Loaded	Fastening Type	Mounting Type	Contact Shape	Number of Rows [custom]	Termination	Contact Type	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Number of Positions	Contact Length - Mating	Contact Length - Mating [x]	Contact Length - Post [x]	Contact Length - Post [x]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Material	Style	Insulation Height	Insulation Height	Insulation Material	Overall Contact Length [x]	Overall Contact Length [x]	Pitch - Mating	Pitch - Mating	Shrouding	Contact Finish - Post
Harwin Inc. M20-9721045	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	20	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9723645	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	72	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9720445	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	8	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9721645	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0		7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9720446	9.94 mm 10.64 mm 11.04 mm 16.54 mm		Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	8	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded	Tin
Harwin Inc. M20-9720346	9.94 mm 10.64 mm 11.04 mm 16.54 mm		Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	6	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded	Tin
Harwin Inc. M20-9720245	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	4	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9720345	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	6	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
Harwin Inc. M20-9720846	9.94 mm 10.64 mm 11.04 mm 16.54 mm		Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	16	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded	Tin
Harwin Inc. M20-9721345	9.94 mm 10.64 mm 11.04 mm 16.54 mm	Gold	Header Cuttable	Black	All	Push-Pull	Through Hole	Square	2	Solder	Male Pin	3 A	-40 C	105 ░C	UL94 V-0	26	7 mm	0.276 in	0.122 in	3.1 mm	0.1 in	2.54 mm	Brass	Board to Board Cable	0.1 in	2.54 mm	Nylon 6T Polyamide (PA6T)	0.496 in	12.6 mm	0.1 "	2.54 mm	Unshrouded
