415-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 58POS 0.1 GOLD PCB
| Part | Insulation Material | Contact Material | Contact Shape | Contact Length - Post | Contact Length - Post | Contact Finish - Post | Material Flammability Rating | Mounting Type | Fastening Type | Contact Finish - Mating | Contact Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Pitch - Mating | Pitch - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Mating | Connector Type | Number of Rows [custom] | Termination | Number of Positions Loaded | Number of Positions | Insulation Height | Insulation Height | Insulation Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 58 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 50 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 14 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 68 positions | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 66 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 52 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 42 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 20 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 60 | 0.124 in | 3.14 mm | Black |
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 0.107 in | 2.71 mm | Tin | UL94 V-0 | Through Hole | Push-Pull | Gold | Female Socket | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | -55 C | 125 °C | Flash | Socket | 2 | Solder | All | 44 | 0.124 in | 3.14 mm | Black |
