PMBT2907 Series

40V, 600 mA, PNP switching transistor

Catalog

40V, 600 mA, PNP switching transistor

Part	Current - Collector (Ic) (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Mounting Type	Grade	Transistor Type	Operating Temperature	Qualification	Power - Max [Max]	Current - Collector Cutoff (Max) [Max]	Vce Saturation (Max) @ Ib, Ic	Package / Case	Frequency - Transition	Voltage - Collector Emitter Breakdown (Max) [Max]	Supplier Device Package
Nexperia USA Inc. PMBT2907AQAZ	600 mA	100 hFE	Surface Mount	Automotive	PNP	150 °C	AEC-Q101	325 mW	10 nA	1.6 V	3-XDFN Exposed Pad	210 MHz	60 V	DFN1010D-3
Nexperia USA Inc. PMBT2907A,215	600 mA	100 hFE	Surface Mount	Automotive	PNP	150 °C	AEC-Q101	250 mW	10 nA	1.6 V	SC-59 SOT-23-3 TO-236-3	200 MHz	60 V	TO-236AB
Nexperia USA Inc. PMBT2907,215	600 mA	100 hFE	Surface Mount	Automotive	PNP	150 °C	AEC-Q101	250 mW	20 nA	1.6 V	SC-59 SOT-23-3 TO-236-3	200 MHz	40 V	TO-236AB
Nexperia USA Inc. PMBT2907A,235	600 mA	100 hFE	Surface Mount	Automotive	PNP	150 °C	AEC-Q101	250 mW	10 nA	1.6 V	SC-59 SOT-23-3 TO-236-3	200 MHz	60 V	TO-236AB
Nexperia USA Inc. PMBT2907AMYL	600 mA	100 hFE	Surface Mount	Automotive	PNP	150 °C	AEC-Q101	250 mW	10 nA	1.6 V	SC-101 SOT-883	210 MHz	60 V	SOT-883

Catalog

40V, 600 mA, PNP switching transistor

Description

PNP switching transistor in an ultra small DFN1010D-3 (SOT1215) leadless Surface-Mounted Device (SMD) plastic package with visible and solderable side pads.
