629-21W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 21POS R/A SLDR
| Part | Contact Material | Voltage Rating | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Features | Material Flammability Rating | Shell Size, Connector Layout | Shell Material, Finish | Flange Feature | Contact Finish | Termination | Backset Spacing | Backset Spacing | Current Rating (Amps) | Contact Type | Connector Style | Connector Type | Contact Finish Thickness | Mounting Type | Number of Rows [custom] | Number of Positions | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets | UL94 V-0 | 4 (DC C) - 21WA4 | Nickel Plated Steel | M3 | Gold | Solder | 9.4 mm | 0.37 in | 5 A 40 A | Signal and Power | Combo D-Sub | Plug Male Pins | Flash | Right Angle Through Hole | 2 | 21 | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Grounding Indents Shielded | UL94 V-0 | 4 (DC C) - 21WA4 | Nickel Plated Steel | Housing/Shell (Unthreaded) | Gold | Solder | 9.4 mm | 0.37 in | 5 A 30 A | Signal and Power | Combo D-Sub | Plug Male Pins | Flash | Right Angle Through Hole | 2 | 21 | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets | UL94 V-0 | 4 (DC C) - 21WA4 | Nickel Plated Steel | Housing/Shell (M3) | Gold | Solder | 9.4 mm | 0.37 in | Signal and Power | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 20A 5A | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets | UL94 V-0 | 21W1 B DB | Nickel Plated Steel | Housing/Shell | Gold | Solder | 9.4 mm | 0.37 in | Coax Signal | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 30 Áin | 0.76 Ám | 3 | 4-40 | |||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Grounding Indents | UL94 V-0 | 4 (DC C) - 21WA4 | Nickel Plated Steel | Board Side (M3) | Gold | Solder | 9.4 mm | 0.37 in | 5 A 30 A | Signal and Power | Combo D-Sub | Plug Male Pins | Flash | Right Angle Through Hole | 2 | 21 | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | 4 (DC C) - 21WA4 | Housing/Shell (M3) | Gold | Solder | 9.4 mm | 0.37 in | 5 A 30 A | Signal and Power | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | 4 (DC C) - 21WA4 | 4-40 | Gold | Solder | 9.4 mm | 0.37 in | Signal and Power | Combo D-Sub | Plug Male Pins | Flash | Right Angle Through Hole | 2 | 21 | 20A 5A | ||||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | 21W1 B DB | Nickel Plated Steel | Housing/Shell | Gold | Solder | 9.4 mm | 0.37 in | Signal and Power | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 10A 5A | 30 Áin | 0.76 Ám | 3 | 4-40 | ||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | 21W1 B DB | Nickel Plated Steel | 4-40 | Gold | Solder | 9.4 mm | 0.37 in | Signal and Power | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 10A 5A | 30 Áin | 0.76 Ám | 3 | |||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | 21W1 B DB | Housing/Shell (M3) | Gold | Solder | 9.4 mm | 0.37 in | Signal and Power | Combo D-Sub | Plug Male Pins | Right Angle Through Hole | 2 | 21 | 10A 5A | 30 Áin | 0.76 Ám | 3 |
