H11L2M Series

6-Pin DIP Schmitt Trigger Output Optocoupler

Catalog

6-Pin DIP Schmitt Trigger Output Optocoupler

Part	Inputs - Side 1/Side 2 [custom]	Voltage - Isolation	Current - Output / Channel	Voltage - Supply [Max]	Voltage - Supply [Min]	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Input Type	Current - DC Forward (If) (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Number of Channels	Output Type	Package / Case	Supplier Device Package	Data Rate	Mounting Type	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Package / Case	Package / Case
ON Semiconductor H11L2SVM	1	4170 Vrms	50 mA	15 V	3 V	4 µs	4 µs	DC	30 mA	85 °C	-40 °C	1	Open Collector	6-SMD Gull Wing	6-SMD	1 MHz	Surface Mount	100 ns	100 ns
ON Semiconductor H11L2M	1	4170 Vrms	50 mA	15 V	3 V	4 µs	4 µs	DC	30 mA	85 °C	-40 °C	1	Open Collector	6-DIP	6-DIP	1 MHz	Through Hole	100 ns	100 ns	0.3 in	7.62 mm
ON Semiconductor H11L2SM	1	4170 Vrms	50 mA	15 V	3 V	4 µs	4 µs	DC	30 mA	85 °C	-40 °C	1	Open Collector	6-SMD Gull Wing	6-SMD	1 MHz	Surface Mount	100 ns	100 ns
ON Semiconductor H11L2VM	1	4170 Vrms	50 mA	15 V	3 V	4 µs	4 µs	DC	30 mA	85 °C	-40 °C	1	Open Collector	6-DIP	6-DIP	1 MHz	Through Hole	100 ns	100 ns	0.3 in	7.62 mm

Catalog

6-Pin DIP Schmitt Trigger Output Optocoupler

Key Features

• High data rate, 1MHz typical (NRZ)

• Free from latch up and oscilliation throughout voltageand temperature ranges.

• Microprocessor compatible drive

• Logic compatible output sinks 16mA at 0.4Vmaximum

• Guaranteed on/off threshold hysteresis

• Wide supply voltage capability, compatible with allpopular logic systems

• Underwriters Laboratory (UL) recognized—file #E90700, Volume 2

• VDE recognized – File#102497 – Add option V(e.g., H11LIVM)

Description

The H11LXM series has a high speed integrated circuitdetector optically coupled to a gallium-arsenide infraredemitting diode. The output incorporates a Schmitttrigger, which provides hysteresis for noise immunity andpulse shaping. The detector circuit is optimized forsimplicity of operation and utilizes an open collectoroutput for maximum application flexibility.
