857-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.156
| Part | Color | Mounting Type | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Contact Material | Card Type | Gender | Termination | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Contact Finish | Pitch | Pitch | Contact Type | Termination Rows | Read Out | Flange Feature | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | Right Angle Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 38 | Copper Alloy | Non Specified - Dual Edge | Female | Solder | 19 | 0.25 Ám | 10 Áin | 2 | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Dual | ||||
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 38 | Copper Alloy | Non Specified - Dual Edge | Female | Solder | 19 | 0.25 Ám | 10 Áin | 2 | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Dual | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder | 19 | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | 1 | ||||
 EDAC Inc. | Black | Right Angle Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 38 | Copper Alloy | Non Specified - Dual Edge | Female | Solder | 19 | 0.25 Ám | 10 Áin | 2 | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Dual | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder Eyelet(s) | 19 | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | Flush Mount Top Opening Unthreaded | 1 | 3.96 mm | 0.156 " | |
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Wire Wrap | 19 | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | Floating Bobbin Flush Mount | 1 | 2.95 mm | 0.116 " | |
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder | 19 | Tin | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | Flush Mount Top Opening Unthreaded | 1 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder | 19 | Tin | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | Flush Mount M3 Threaded Insert Top Opening | 1 | |||||
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder | 19 | Tin | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | Flush Mount M3 Threaded Insert Top Opening | 1 | |||||
 EDAC Inc. | Black | Through Hole | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 19 | Copper Alloy | Non Specified - Single Edge | Female | Solder Eyelet(s) | 19 | Tin | 3.96 mm | 0.156 in | Semi Bellows | 1 | Single | 4-40 Flush Mount Threaded Insert Top Opening | 1 |
