DEUTSCH HDP Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
REC, 19P, BLK, E, THD, 12/16, S
| Part | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Note | Insert Material [custom] | Insert Material [custom] | Mounting Feature | Fastening Type | Shell Size - Insert [Max] | Shell Size - Insert [Min] | Features | Number of Positions | Ingress Protection | Material Flammability Rating | Mounting Type | Shielding | Primary Material | Shell Material | Housing Color | Contact Size | Orientation | Connector Type | Contact Type | Type | Shell Size - Insert [Min] [custom] | Shell Size - Insert [Max] [custom] | Insert Material | Number of Positions [custom] | Shell Size - Insert | Contact Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Nylon | Polyamide (PA) | Bulkhead - Front Side Nut | Threaded | 24 | 19 | Dust Cap Thread Adapter | 19 | IP67 - Dust Tight Waterproof | UL94 V-1 | Panel Mount | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | 12 16 | Keyed | Receptacle Housing | Crimp | For Female Sockets | ||||||
 TE Connectivity AMP Connectors | Bayonet Lock | Coupling Nut | 20 | IP67 - Dust Tight Waterproof | UL94 V-0 | Free Hanging (In-Line) | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | 16 20 | Keyed | Plug Housing | Crimp | For Female Sockets | 18 | 20 | |||||||||||||
 TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Bayonet Lock | 24 | 19 | Coupling Nut | 19 | IP68 - Dust Tight Waterproof | UL94 V-1 | Free Hanging (In-Line) | Unshielded | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | 12 16 | Keyed | Plug Housing | Crimp | For Male Pins | Polyetherimide (PEI) | |||||||||
TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Bayonet Lock | 31 | 24 | Coupling Nut Threading Adapter | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) | Unshielded | Glass Filled Nylon 6/6 Polyamide (PA66) | Black Blue | 16 | Keyed | Plug Housing | Crimp | For Female Sockets | Polyetherimide (PEI) | 31 | ||||||||||
 TE Connectivity AMP Connectors | Bulkhead - Front Side Nut | Bayonet Lock | Ring Adapter | 8 | IP68 - Dust Tight Waterproof | UL94 V-1 | Panel Mount | Unshielded | Glass Filled Nylon 6/6 Polyamide (PA66) | Black Blue | 12 | Keyed | Receptacle Housing | Crimp | For Male Pins | 18-8 | ||||||||||||||
 TE Connectivity AMP Connectors | Bayonet Lock | 24 | 18 | Coupling Nut Ring Adapter | 18 | IP67 - Dust Tight Waterproof | UL94 V-0 | Free Hanging (In-Line) | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | Keyed | Plug Housing | Crimp | For Female Sockets | 12 (3) 16 (14) 8 (1) | |||||||||||||
 TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Nylon | Polyamide (PA) | Bulkhead - Front Side Nut | Threaded | 21 | 24 | Dust Cap Thread Adapter | 21 | IP67 - Dust Tight Waterproof | UL94 V-1 | Panel Mount | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | Keyed | Receptacle Housing | Crimp | For Male Pins | 12 (4) 16 (17) | ||||||
 TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Bayonet Lock | 24 | 19 | Coupling Nut Ring Adapter | 19 | IP67 - Dust Tight Waterproof | UL94 V-0 | Free Hanging (In-Line) | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | 12 16 | Keyed | Plug Housing | Crimp | For Male Pins | |||||||||
 TE Connectivity AMP Connectors | Circular | -55 C | 125 °C | Contacts Not Included | Bayonet Lock | 24 | 18 | Coupling Nut Ring Adapter | 18 | IP67 - Dust Tight Waterproof | UL94 V-0 | Free Hanging (In-Line) | Unshielded | Plastic | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | Keyed | Plug Housing | Crimp | For Male Pins | 12 (3) 16 (14) 8 (1) | |||||||||
 TE Connectivity AMP Connectors | Bulkhead - Front Side Nut | Bayonet Lock | 16 | 24 | Dust Cap | 16 | IP68 - Dust Tight Waterproof | UL94 V-1 | Panel Mount | Unshielded | Glass Filled Nylon 6/6 Polyamide (PA66) | Black | 12 | Keyed | Receptacle Housing | Crimp | For Female Sockets |
