860-R03 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 3POS GOLD SOLDER
| Part | Contact Material | Color | Current Rating (Amps) | Material Flammability Rating | Orientation | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Primary Material | Shell Size - Insert | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Ingress Protection | Shell Finish | Shielding | Mounting Feature | Voltage Rating | Contact Finish - Mating | Mounting Type | Shell Material | Applications | Termination | Insert Material | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | Silver | 4 A | UL94 V-0 | A | 85 °C | -40 C | Plug Female Sockets | Metal | M12-3 | 0.25 µm | 10 µin | IP67 - Dust Tight Waterproof | Nickel | Shielded | Bulkhead - Front Side Nut | 250 V | Gold | Panel Mount Through Hole | Brass | Industrial Medical | Solder | Polybutylene Terephthalate (PBT) | Threaded |
