1583A Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE CAT5E 8COND 24AWG YL
| Part | Cable Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Material | Length | Length | Conductor Insulation | Conductor Insulation | Ratings | Number of Conductors | Conductor Strand | Wire Gauge | Conductor Material | Jacket Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Yellow | Rip Cord |
 Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Green | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Green | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Orange | Rip Cord |
 Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | White | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Pink | Rip Cord |
 Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | White | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Pink | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | Yellow | Rip Cord |
Belden Inc. | Multi-Pair Cat5e | 0.19 in | 4.83 mm | -20 ░C | 60 °C | Poly-Vinyl Chloride (PVC) Riser | 914.4 m | 3000 ' | Polyolefin | PO | UL Style CMR | 8 | Solid | 24 AWG | Copper Bare | White | Rip Cord |
