Panel Pot
Panel Pot
| Part | Bushing Thread | Power (Watts) | Power (Watts) | Built in Switch | Adjustment Type | Size - Body [diameter] | Size - Body [diameter] | Taper | Termination Style | Resistive Material | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Actuator Type | Rotation | Tolerance | Mounting Type | Actuator Length [x] | Actuator Length [x] | Number of Turns | Number of Gangs | Resistance (Ohms) | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TT Electronics/BI | 3/8-32 | 0.25 W | 0.25 W | None | User Defined | 0.945 " | 24 mm | Logarithmic | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Slotted | 300 ░ | 20 % | Panel Mount | 0.787 in | 20 mm | 1 | 1 | 500 kOhms | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.787 in | 20 mm | 1 | 1 | 500 kOhms | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.591 in | 15 mm | 1 | 1 | 10k | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.984 in | 25 mm | 1 | 1 | 100k | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.787 in | 20 mm | 1 | 1 | 150k | |
TT Electronics/BI | 3/8-32 | 0.25 W | 0.25 W | None | User Defined | 0.945 " | 24 mm | Logarithmic | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.787 in | 20 mm | 1 | 1 | 250000 Ohms | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Knurled and Slotted | 300 ░ | 20 % | Panel Mount | 0.748 in | 19 mm | 1 | 1 | 250000 Ohms | |
TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6 mm | 0.236 in | Knurled and Slotted | 300 ░ | 20 % | Panel Mount | 0.63 in | 16 mm | 1 | 1 | 300k | |
 TT Electronics/BI | 3/8-32 | 0.5 W | 0.5 W | None | User Defined | 0.945 " | 24 mm | Linear | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Flatted | 300 ░ | 20 % | Panel Mount | 0.984 in | 25 mm | 1 | 1 | 1k | |
TT Electronics/BI | 3/8-32 | 0.25 W | 0.25 W | None | User Defined | 0.945 " | 24 mm | Logarithmic | Solder Lug | Conductive Plastic | 6.35 mm | 0.25 in | Slotted | 300 ░ | 20 % | Panel Mount | 0.787 in | 20 mm | 1 | 1 | 1 MΩ |
