MAX2829 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
IC RF TXRX WIFI 56TQFN
| Part | RF Family/Standard | Power - Output | Mounting Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Protocol | Supplier Device Package | Frequency | Current - Receiving [Min] | Current - Receiving [Max] | Modulation | Serial Interfaces | Current - Transmitting [Max] | Current - Transmitting [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Sensitivity | Data Rate (Max) [Max] | Package / Case | Type | For Use With/Related Products | Supplied Contents | Frequency [Min] | Frequency [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | WiFi | -2 dBm | Surface Mount | 2.7 V | 3.6 V | 800.11g 802.11a 802.11b | 56-TQFN (8x8) | 2.4 GHz 5 GHz | 118 mA | 210 mA | CCK DSSS OFDM | SPI | 157 mA | 142 mA | 85 °C | -40 °C | -75 dBm | 54 Mbps | 56-WFQFN Exposed Pad | TxRx Only | ||||
 Analog Devices Inc./Maxim Integrated | Transceiver | MAX2829 | Board(s) | 2.4 GHz 4.9 GHz | 2.5 GHz 5.875 GHz |
