SIT9003 Series

Manufacturer: SiTime

Catalog

Catalog

MEMS OSC XO 25.0000MHZ LVCMOS LV

...

Part	Frequency	Voltage - Supply	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Function	Frequency Stability	Supplier Device Package	Current - Supply (Max) [Max]	Type	Package / Case	Output	Base Resonator	Size / Dimension [y]	Supplier Device Package [x]	Supplier Device Package [y]	Spread Spectrum Bandwidth	Height - Seated (Max)	Current - Supply (Disable) (Max) [Max]
SiTime SIT9003AC-83-33ED-25.00000	25 MHz	3.3 V	0.039 in	1 mm	-20 ░C	70 °C	5 mm	7 mm	0.197 "	0.276 "	Surface Mount	Enable/Disable	50 ppm	4-PQFN (7x5)	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS
SiTime SIT9003AI-33-33DB-32.00000	32 MHz	3.3 V	0.031 in		-40 C	85 °C		5 mm	0.126 in	0.197 in	Surface Mount		50 ppm	4-PQFN	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS	3.2 mm	5	3.2	0.25 %	0.8 mm
SiTime SIT9003AI-43-33DO-7.62750Y	7.6275 MHz	3.3 V	0.039 in	1 mm	-40 C	85 °C	5 mm	7 mm	0.197 "	0.276 "	Surface Mount		50 ppm	4-SMD (7x5)	4.1 mA	XO (Standard)	4-SMD No Lead Exposed Pad	LVCMOS LVTTL	MEMS				-1 %		4.3 µA
SiTime SIT9003AC-13-33DQ-66.66666Y	66.66666 MHz	3.3 V	0.031 in		-20 ░C	70 °C	2 mm	2.5 mm	0.079 in	0.098 in	Surface Mount		50 ppm	4-PQFN	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		2.5	2	-1 %	0.8 mm	4.3 µA
SiTime SIT9003AI-13-18DQ-45.00000	45 MHz	1.8 V	0.031 in		-40 C	85 °C	2 mm	2.5 mm	0.079 in	0.098 in	Surface Mount		50 ppm	4-PQFN	3.5 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		2.5	2	-1 %	0.8 mm	0.8 µA
SiTime SIT9003AI-13-33EB-24.00000T	24 MHz	3.3 V	0.031 in		-40 C	85 °C	2 mm	2.5 mm	0.079 in	0.098 in	Surface Mount	Enable/Disable	50 ppm	4-PQFN	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		2.5	2		0.8 mm	4.3 µA
SiTime SIT9003AI-13-18DQ-45.00000Y	45 MHz	1.8 V	0.031 in		-40 C	85 °C	2 mm	2.5 mm	0.079 in	0.098 in	Surface Mount		50 ppm	4-PQFN	3.5 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		2.5	2	-1 %	0.8 mm	0.8 µA
SiTime SIT9003AI-13-33DB-14.74560Y	14.7456 MHz	3.3 V	0.031 in		-40 C	85 °C	2 mm	2.5 mm	0.079 in	0.098 in	Surface Mount		50 ppm	4-PQFN	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		2.5	2	0.25 %	0.8 mm
SiTime SIT9003AC-23-33DD-25.00000Y	25 MHz	3.3 V	0.031 in		-20 ░C	70 °C	2.5 mm	3.2 mm	0.098 in	0.126 "	Surface Mount		50 ppm	4-PQFN	4.1 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		3.2	2.5	0.5 %	0.8 mm	4.3 µA
SiTime SIT9003AC-23-18ED-40.000000T	40 MHz	1.8 V	0.031 in		-20 ░C	70 °C	2.5 mm	3.2 mm	0.098 in	0.126 "	Surface Mount	Enable/Disable	50 ppm	4-PQFN	3.5 mA	XO (Standard)	4-SMD No Lead	LVCMOS LVTTL	MEMS		3.2	2.5		0.8 mm	0.8 µA
