83394 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 22AWG RED SHLD
| Part | Shield Coverage | Shield Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Cable Type | Length | Length | Jacket (Insulation) Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Shield Type | Jacket Color | Ratings | Number of Conductors | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Insulation | Wire Gauge | Usage | Operating Temperature [Max] | Operating Temperature [Min] | Features | Conductor Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | 5.06 mm | 0.199 in | Multi-Conductor | 152.4 m | 500 ft | Silicone Rubber | 0.03 in | 0.762 mm | Foil | Red | UL Style 4516 | 2 | 30 AWG | 7 | Fluorinated Ethylene-Propylene (FEP) | 22 AWG | Communication Control Instrumentation | 150 °C | -70 °C | Drain Wire | Copper Tinned |
